The following sections provide a detailed description on how to represent a Technical Publication DEX using the PLCS PSM.

The information that can be exchanged by the Technical Publication DEX has been summarised in the Business Information Requirements section.

NOTE    An explanation of a template and its specification is provided in the Template overview
Message Technical Publication
../../../../../data/contexts/SwedishDefence/dexs/TechnicalPublication/images/MessageTechnicalPublicationDEXPlcsRep.png
Figure 7 -  SysML Block Definition diagram representing the Message Task Method
